COVNA 2V025 06 Low Pressure Mininature Air Solenoid Valve
Mininature direct acting, 2/2 way normally closed pneumatic solenoid valve, dc 12v, 1/4 inch, working pressure: 0 to 1.0MPa, female thread. NBR sealed. No MOQ.
- Model: 2V025
- Size Range: 1/4
- Pressure Range: 0~1.0MPa
- Material: Aluminum Alloy
DC 12v Solenoid Coil Neumatica Valvula Solenoide 2v025
| Model | 2V025 | Voltage | 12V DC |
| MOQ | 1 Set | No. of Ways | 2/2 Way |
| Pipe Size | 1/4 inch | Operation | Direct Acting |
| Orifice | 4mm | Switching Function | Normally Closed (NC) |
| Operating Pressure | 0 to 1.0MPa | Media | Air |
| Body Material | Aluminum Alloy | Temp. of Media | 20°C to 80°C |
| Sealing Material | NBR | Certification | ISO 9001, CE, TUV, SGS |
| End Connection | Female Thread | Warranty | 1 Year (12 Months) |
| Model | Specification |
| S91B Solenoid Coil | Voltage: AC 24V/110V/220V/240V, 50/60Hz; DC 12V/24V/48V
Power Consumption: AC: 22VA; DC: 17W
Protection Class: H
|
| S41B Solenoid Coil | Voltage: AC 24V/110V/220V/240V, 50/60Hz; DC 12V/24V/48V Power Consumption: AC: 18VA; DC: 11W Protection Class: H |
| Ex1620 Ex-proof Coil | Voltage: AC 220V, 50Hz; DC 24V Power Consumption: AC: 20VA; DC: 16W Protection Class: H |
