COVNA 2W31 Direct Acting Brass Water Solenoid Valve 1/2 Inch
2W31 Stainless Steel 12v Solenoid Control Ball Valve applied to low pressure system with harder valve body; Durable brass construction and a quality copper solenoid coil, not aluminium coil. Two position two way, magnetic solenoid water valve; Adapt new technology, each valve is individually tested, trustworthy, industrial grade highly reliable
- Model: 2W31
- Size Range: 3/8''~2''
- Pressure Range: 0-1.0 MPa (10 bar)
- Material: Brass or stainless steel UPVC
| Port Size | 3/8″, 1/2″, 3/4″, 1″, 1¼”, 1½”, 2″ | Orifice(mm) | 10,15, 20, 25, 32, 40, 50 |
| Port Thread | G, BSPP, BSPT, NPT, FLANGE | Function | Normally closed or opened |
| Pressure | 0-1.0 MPa (10 bar) | Voltage | DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz |
| Temperature of media | -10~80℃ (14℉ to 176℉) | Suitable Media | Water, Air, Oil, Gas, etc |
| Material | Brass or stainless steel UPVC | Sealing Material | NBR, PTFE, EPDM |
| Coil | S91B,22VA(AC),17W(DC),IP65,100%ED | ||
| Coil | S92B,22VA(AC),17W(DC),IP65,100%ED | ||
| Coil | SD01B,28VA(AC),36W(DC),IP65,100%ED | ||
- 2W31 electric solenoid valve direct lifting diaphragm construction with high frequency water, oil. Flexible to control
- Used to control automatically the liquid and gas in the piepline
- Widely used for various applications such as environmental protection, argriculture irrigation, water treatement, automatic euqipment, and so on
COVNA group valves factories located in Ningbo city, Wenzhou city in China is a famous and trustworthy automatic valves suppliers.
