COVNA Normally Open Stainless Steel Food Grade Sanitary Solenoid Valve
COVNA solenoid valve with fast speed, small power, light shape. The response time of the solenoid valve can be as short as several milliseconds, and even the pilot solenoid valve can be controlled within tens of milliseconds. Because of self-contained loop, it is more sensitive than other automatic control valves. The properly designed solenoid valve coil has low power consumption, which is an energy-saving product; it can also be used to trigger action and automatically maintain the valve position without any power consumption at ordinary times. The external dimension of the solenoid valve is small, which not only saves space, but also is light and beautiful
- Model: HK0018
- Size Range: 3/8''~2''
- Pressure Range: 0.0MPa-1.6 MPa
- Material: Stainless Steel
Solenoid Valve Product features high Quality Standards, modular design, long life, tight shutoff and applies in Instrumentation Equipment, Analyzers and Diagnostic Equipment, Medical and Dental Equipment, Portable Welding Equipment, Spraying Equipment, Lubrication Equipment, Beverage Dispensing & Vending machines
| Port Size | 3/8”, 1/2″, 3/4″, 1″, 1¼”, 1½”, 2″ | Orifice(mm) | 19,25,32,38,45,51,57,63,76,89,102 |
| Port Connection | Clamp | Function | Normally closed or opened |
| Pressure | 0.00MPa-1.6MPa | Voltage | DC-12V, 24V, 36V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz |
| Temperature of media | -10~180℃ ;-10~220℃ | Suitable Media | Stem, hot water, civil gas, air oil. |
| Material | Stainless steel | Sealing Material | EPDM, VITON,NBR, PTFE |
| Coils | Y32B, Y42B, S51BSD01B, EX1620 | ||
COVNA’s comprehensive selection of solenoid valves includes a broad range of types and configurations for all manner of applications across many industrial markets. We can supply a superior array of solenoid valve solutions, covering a wide selection of function and material types. Our solenoid valve family of products offers countless benefits, including peerless reliability, compact and lightweight space-saving options, exceptional flow control, high pressure capabilities, and an excellent return on investment.
