COVNA Stainless Steel Flanged Manual Gate Valve
COVNA Stainless Steel Flanged Manual Gate Valve Pressure drop during operation is very less. Most of the gate valve can be used as bi-directional They are suitable for high pressure and temperature application and required less maintenance Manufacture & Design Standard: GB、DIN、ANSI etc. – DESCRIPTION – A flange wedge gate valve can be defined […]
- Model: Manual Gate Valve
- Size Range: 1" ~ 16"
- Pressure Range: 1.6 to 10 MPa
- Material: Stainless steel
COVNA Stainless Steel Flanged Manual Gate Valve
- Pressure drop during operation is very less.
- Most of the gate valve can be used as bi-directional
- They are suitable for high pressure and temperature application and required less maintenance
- Manufacture & Design Standard: GB、DIN、ANSI etc.
– DESCRIPTION –
A flange wedge gate valve can be defined as a type of valve that used a gate or wedge type disk and the disk moves perpendicular to flow to start or stop the fluid flow in piping.
A gate valve is the most common type of valve that used in any process plant. It is a linear motion valve used to start or stop fluid flow. In service, these valves are either in fully open or fully closed position. When the gate valve is fully open, the disk of a gate valve is completely removed from the flow. Therefore virtually no resistance to flow. Due to this very little pressure drops when fluid passes through a gate valve.
To achieve proper sealing, when the valve is fully closed, 360° surface contact is required between disk and seats.
