HK60-D Cast Iron Wafer Type Motorized Operated Butterfly Valve
Large size range for choice. 2 inches to 24 inches. It can work for a long time 99 hours. Echo-friendly and easy installation. Manual override is available. Suitable for hot and cold water. Standard on/off control, 4-20mA or 0-10VDC modulating control is available, cast iron or ductile iron body construction, optional 304 or 316 stainless steel. Widely used for different applications such as HVAC, water treatment and so on for flow control.
Actuator type: intelligence type, modulating type, on/off type.
- Model: HK60-D
- Size Range: 2'' to 24''
- Pressure Range: 1.0MPa~1.6MPa
- Material: Cast Iron
Motor Actuator Operated Butterfly Valve DN80
- Port Size Range: Normally from 2 inch to 24 inch. Special size could be customized
- Bubbles-tight sealing with no leakage under the pressure test
- Easy automation/Retrofit possible
- Wide selections of materials, applicable for various medium
- 100% tight Bidirectional shut off
| ON/OFF Type | Feedback: the active contact signal, passive contact signal, resistance, 4-20mA |
| Regulation Type | Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V |
| Field operation | The Field, Remote Control Switch Regulation and MODBUS, PROFIBUS Field Bus |
| Voltage Optional | AC110-240V 380V 50/60HZ: DC12V, DC24V, Special Voltage Can be Customized |
| Protection Class | IP65, Explosion Proof Construction Are Available: EX ll BT4 |
| Valve Body | Valve components | ||
| Nominal size | DN50-DN600 | Sealing material | NBR, EPDM, PTFE |
| Body Material | Cast Iron | Disc Material | SS, CI, Ductile Iron, WCB |
| End Connection | Wafer, Flange | Stem Material | Stainless Steel |
| Operating Pressure | 1.0 / 1.6 / 2.0 / 6.4 MPa (10 / 16 / 20 / 64 bar) | Applicable media | Water, Air, Gas, Oil, Liquid |
| Structure | Midline structure/A-Type | Design standard | ISO, DIN, IDF, SMS, 3A |
| Series | 5 | 10 | 16 | 30 | 60 | 125 | 250 | 400 |
| Torque Output | 50Nm | 100Nm | 160Nm | 300Nm | 600Nm | 1250Nm | 2500Nm | 4000Nm |
| 90° Cycle Time | 20S | 15/30S | 15/30S | 15/30S | 30S | 100S | 100S | 100S |
| Angle Of Rotation | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° |
| Working Current | 0.23A | 0.35A | 0.4A | 0.45A | 0.6A | 1.03A | 1.85A | 2.7A |
| Drive Motor | 50W | 75W | 80W | 100W | 130W | 210W | 285W | 360W |
| Mounting Standard | ISO5211 direct mounting | |||||||
| Voltage Options | DC12V, DC24V, AC24V, AC110V, AC220V, AC380V | |||||||
| Input Signal | 4-20mA, 1-5VDC, 0-10VDC | |||||||
| Output Signal | 4-20mA, 1-5VDC, 0-10VDC | |||||||
| Protection Class | IP65 protection class | |||||||
| Ambient Temp | -20 to +60°C | |||||||
| Wiring Diagram | A: ON/OFF type with light indicator signal feedback | |||||||
| B: ON/OFF type with passive contact signal feedback | ||||||||
| C: ON/OFF type with resisance potentiometer signal feedback | ||||||||
| D: ON/OFF type with resistance potentiometer and neutral posistion signal feedback | ||||||||
| E: Regulation type with servo control module | ||||||||
| F: DC24/DC12V direct ON/OFF type | ||||||||
| G: AC380V 3-phase power supply with passive signal feedback | ||||||||
| H: AC380V 3-phase power supply with resistance potentiometer and neutral posistion signal feedback | ||||||||
