COVNA HK60-D-C Cast Iron Electric Actuator Fluorine Lined Butterfly Valve
This wafer type butterfly valve is for chemical industry. Adopt PTFE as the seal and disc which has a powerful ability of anti-corrosion. Suitable for acid, alkali, and other media flow control. Disc plate with frame structure, high strength, flow area, flow resistance. The valve with more and more tightly sealed off function, a reliable sealing performance.
- Model: HK60-D-C
- Size Range: 2'' to 16''
- Pressure Range: 1.0MPa~1.6MPa
- Material: Cast Iron, PTFE
Anti-corrosive Motorized Control Butterfly Valve
- Torque range is 50Nm(442 in-lb) to 2500Nm(22123 in-lb).
- It could be equipped with on off type actuator, modulating type actuator and intelligent type actuator
- Easy automation/Retrofit possible/Safe operation
- Steam lined valve disc ensures lower pressure drop
- Size range from 2 inch to 16 inch, size ia available to custom
| ON/OFF Type | Feedback: the active contact signal, passive contact signal, resistance, 4-20mA |
| Regulation Type | Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V |
| Field operation | The Field, Remote Control Switch Regulation and MODBUS, PROFIBUS Field Bus |
| Voltage Optional | AC110-240V 380V 50/60HZ: DC12V, DC24V, Special Voltage Can be Customized |
| Protection Class | IP65, Explosion Proof Construction Are Available: EX ll BT4 |
| Torque Range |
50Nm to 2500Nm |
| Valve Body | Valve components | ||
| Nominal size | DN50-DN400 | Sealing material | PTFE |
| Body Material | Cast Iron,WCB,304,316 | Disc Material | PTFE |
| End Connection | wafer, flange, lug wafer | Feature | Acid and alkali resistant |
| Operating Pressure | PN1.0MPa, PN1.6MPa | Applicable media | Water, Air, Gas, Oil, Liquid |
| Structure | Midline structure/A-Type | Design standard | ISO, DIN, IDF, SMS, 3A |
