HK60-Q-F-Z Intelligent Modulating Electric Actuated Ball Valve
Could be equipped with modulating or on-off electric actuator. Available in local / remote control electric actuator with LCD display screen to achieve the goal of industrial automation.
Available in 4-20mA, 0-10V DC or 1-5V DC signal controls. Widely used for irrigation system, wastewater treatment, etc.
This 300 pound flanged auto ball valve is a two piece, two way valve that can be installed into whatever position your unique machinery calls for, making it highly versatile as well.
Its NEMA 4/4X weatherproof enclosure works with its anti-static nature to help ensure that it never wears down, while the 304 stainless steel composition provides it an extra layer of strength. Our motorized ball valve features a 20 second 90 degree cycle time.
- Model: HK60-Q-F-Z
- Size Range: 1/2'' to 8''
- Pressure Range: 1.6 to 6.4MPa
- Material: WCB, Stainless Steel
High Pressure 2 Way Flange Electric Motorized Ball Valve
- ON-OFF Type: The Active Contact Signal, Passive Contact Signal, Resistance, 4-20mA
- Regulation Type: Input & Output Signal: DC 4-20mA, DC 0-10V, DC 1-5V
- Available in manual control, signal control and AC/DC power supply
| Size Range | DN15-200 | Body Material | Stainless Steel |
| Core Materal | Stainless Steel, WCB | End Connection | Flange |
| Working Pressure | 1.0 / 1.6 / 2.0 / 6.4 MPa (10 / 16 / 20 / 64 bar) | Suitable Media | Water, Air, Oil, Gas, etc |
| Temperature Of Media | -10~180℃ (14℉~356℉) | Structure | Straight Through Flow Path |
| Voltage | DC-12V, 24V; AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz | Voltage Tolerance | ±10% |
● ON/OFF Type Electric Actuator: 90 degree rotation. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.
● Modulating Type Electric Actuator: Adjust open/close angle from 0 to 90 degree. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.
● Intelligent Type Electric Actuator: Adjust open/close angle from 0 to 90 degree. LED display screen to allow you check the open/close angle easier. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.
| ON/OFF Type | Feedback: the active contact signal, passive contact signal, resistant, 4-20mA |
| Regulation Type | Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V |
| Intelligent Type | Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V |
| Field Operation | The field, remote control switch regulation and MODBUS, PROFIBUS field bus |
| Voltage optional | AC 110-240V 380V 50/60Hz; DC12V, DC24V, Special voltage can be customized |
| Protection Class | IP65 |
| Series | 5 | 10 | 16 | 30 | 60 | 125 | 250 | 400 |
| Torque Output | 50Nm | 100Nm | 160Nm | 300Nm | 600Nm | 1250Nm | 2500Nm | 4000Nm |
| 90° Cycle Time | 20S | 15/30S | 15/30S | 15/30S | 30S | 100S | 100S | 100S |
| Angle Of Rotation | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° | 0-90° |
| Working Current | 0.23A | 0.35A | 0.4A | 0.45A | 0.6A | 1.03A | 1.85A | 2.7A |
| Drive Motor | 50W | 75W | 80W | 100W | 130W | 210W | 285W | 360W |
| Mounting Standard | ISO5211 direct mounting | |||||||
| Voltage Options | DC12V, DC24V, AC24V, AC110V, AC220V, AC380V | |||||||
| Input Signal | 4-20mA, 1-5VDC, 0-10VDC | |||||||
| Output Signal | 4-20mA, 1-5VDC, 0-10VDC | |||||||
| Protection Class | IP65 protection class | |||||||
| Ambient Temp | -20 to +60°C | |||||||
| Wiring Diagram | A: ON/OFF type with light indicator signal feedback | |||||||
| B: ON/OFF type with passive contact signal feedback | ||||||||
| C: ON/OFF type with resisance potentiometer signal feedback | ||||||||
| D: ON/OFF type with resistance potentiometer and neutral posistion signal feedback | ||||||||
| E: Regulation type with servo control module | ||||||||
| F: DC24/DC12V direct ON/OFF type | ||||||||
| G: AC380V 3-phase power supply with passive signal feedback | ||||||||
| H: AC380V 3-phase power supply with resistance potentiometer and neutral posistion signal feedback | ||||||||
COVNA aims to provide our customers the best quality products with the most competitive pricing, on-time delivery and full warranty service with omprehensive service from start to finish, encompassing consultation through to after sales service, full support in every respect and ensure that you are accompanied at each stage of your project.
- 20 years manufacturer of actuated valves
- Mass customaztion acceptable. 3 production base, large stock,
- Short lead time, same day shipping.
- German imported manufacturing facilities, 100% Q.C passed before shipping, quality assured.
- Industrial standard 1 year (12 months) warranty.
- ISO 9001 certificated, with extra certifications include CE, TUV, RoHS, SGS, BV, explosion & fire safe.
- OEM / ODM service available. Can do JIS 5K / 10K, ANSI 150lb / 300lb / 600lb / 900lb standard.
